T523W476M035APE100

T523, Tantalum, Polymer Tantalum, Reduced Volume, 47 uF, 20%, 35 VDC, SMD, Polymer, Molded, Face Down Terminals, 100 mOhms, 7343, Height Max = 1.5 mm, Lead Spacing = 1.3 mm

Typical Electrical Performance
The K-SIM Part Details Integration feature is intended to be used on desktop computers only. Please switch to a desktop device in order to use this feature.
Specifications

Specifications

General

Capacitance 47 uF
Tolerance 20%
Voltage DC 35 VDC
Temperature Range -55/+105°C
RoHS Yes
ESR 100 mOhms
Leakage Current 164.5 uA
Footprint 7343
Height Max 1.5 mm
Lead Spacing 1.3 mm
Packaging T&R, 178mm
Packaging Quantity 1000
