T521D107M025ATE050

T521, Tantalum, Polymer Tantalum, 100 uF, 20%, 25 VDC, SMD, Polymer, Molded, Low ESR, Non-Combustible, 50 mOhms, 7343, Height Max = 3.1 mm, Lead Spacing = 1.3 mm

Typical Electrical Performance
The K-SIM Part Details Integration feature is intended to be used on desktop computers only. Please switch to a desktop device in order to use this feature.
Specifications

Specifications

General

Capacitance 100 uF
Tolerance 20%
Voltage DC 25 VDC
Temperature Range -55/+125°C
RoHS Yes
ESR 50 mOhms
Leakage Current 250 uA
Footprint 7343
Height Max 3.1 mm
Lead Spacing 1.3 mm
Packaging T&R, 178mm
Packaging Quantity 500
