T520T107M006APE055

T520, Tantalum, Polymer Tantalum, 100 uF, 20%, 6.3 VDC, SMD, Polymer, Molded, Low Profile/ESR, NonCombustible, 55 mOhms, 3528, Height Max = 1.2 mm, Lead Spacing = 0.8 mm

Typical Electrical Performance
The K-SIM Part Details Integration feature is intended to be used on desktop computers only. Please switch to a desktop device in order to use this feature.
Specifications

Specifications

General

Capacitance 100 uF
Tolerance 20%
Voltage DC 6.3 VDC
Temperature Range -55/+105°C
RoHS Yes
ESR 55 mOhms
Leakage Current 63 uA
Footprint 3528
Height Max 1.2 mm
Lead Spacing 0.8 mm
Packaging T&R, 178mm
Packaging Quantity 3000
